About This Item
Description
The H90 runs two Eventide algorithms at the same time and lets you place them anywhere in your rig, so a granular reverb can sit in the amp loop while a polyphonic pitch shifter stays out front, and Programs change with true spillover.
Which Eventide Harmonizer is this?
The H90 is the two-engine flagship: 74 algorithms, two of them running at once inside every Program, four inputs and four outputs, and two inserts that can be placed anywhere in the chain including an amp effects loop. The H90 Dark Harmonizer is the same platform in a limited black colorway, so it behaves identically. The compact H9 Harmonizer Gen 2 carries the same modern algorithm library but runs one algorithm at a time in a much smaller enclosure with a simpler knob workflow, and the earlier H9 Max Dark is the legacy 52-algorithm generation of that compact format. Choose the H90 when you want two effects and complex routing; choose an H9 when you want one great effect and a small footprint.
Why guitarists choose the H90
- Two algorithms run simultaneously in every Program, in series or in parallel, which replaces two separate pedals and the patching between them.
- Two inserts can be placed independently anywhere in your signal chain, so one half of the H90 can sit in front of the amp while the other lives in the effects loop.
- 74 algorithms cover reverb, delay, modulation, pitch shifting, granular, distortion and the Harmonizer+ vocal suite derived from the flagship H9000.
- True spillover between Programs means reverb and delay tails survive a Program change, which is the difference between a rehearsal tool and a gig tool.
- Four inputs and four outputs plus Dual Mode handles two independent stereo signals or a four-cable-method rig without an extra switcher.
- H90 Control connects over Bluetooth or USB-C from a computer or iPad for deep editing, User Lists and preset management away from the front panel.
Controls and switches
- PERFORM footswitches Three footswitches that handle Program changes, preset and insert bypass with momentary states, and mappable functions including tap tempo.
- Display and encoders Show both running algorithms at once and give direct access to their parameters without menu diving.
- Exp/Ctl 1 and 2 Two 1/4" TRS jacks that accept expression pedals, aux switches of up to three buttons, or CV.
- Routing controls Set series or parallel operation, insert placement and Dual Mode for two independent stereo paths.
- MIDI and USB-C Five-pin DIN MIDI In and Out/Thru plus USB-C for control, updates and MIDI.
Power and pedalboard compatibility
Runs on a 12V DC center-positive supply through a 5.5 / 2.5 mm barrel jack and draws up to 1000 mA (1 A). A standard 9V pedalboard rail cannot feed it, so use the included universal 12V supply or a dedicated board output rated 12V at 1 A or more. Eventide does not publish a true-bypass claim for this platform: preset bypass and insert bypass are mapped to the PERFORM footswitches instead, with momentary states available, and the two inserts can be placed anywhere in the chain including an amp effects loop.
Technical specifications
| Type | Dual-algorithm floor multi-effects and Harmonizer processor |
|---|---|
| Dimensions | 13.6 x 17.0 x 6.8 cm (L x W x H) |
| Algorithms and presets | 74 algorithms, two running at once; hundreds of curated Programs with true spillover |
| Audio I/O | Inputs 1-4 and Outputs 1-4, all 1/4" TS mono jacks, instrument or line level |
| Control connections | Exp/Ctl 1-2: 1/4" TRS for expression pedals, up to 3-button aux switches and CV. USB Type-C for control, updates and MIDI. 5-pin DIN MIDI In and MIDI Out/Thru. |
| Wireless control | H90 Control over Bluetooth or USB-C from a computer or iPad |
| Maximum input level | +4 dBu (instrument) / +14 dBu (line) |
| Recommended load impedance | 10 kOhm |
| Weight | 840 g |
| Input impedance | 600 kOhm |
| Output impedance | 220 Ohm |
| Current draw | Up to 1000 mA |
| Power | 12V DC center positive, 5.5 / 2.5 mm barrel, up to 1000 mA; supply included |
| Signal path | Digital |
| Warranty | One year |
Reference: the official Eventide H90 page and the official manual.
FAQ
Can the H90 really run two effects at once? Yes. Every Program loads two of the 74 algorithms and runs them together, in series or in parallel, and you can place the two inserts at different points in your rig.
Will a 9V pedalboard supply run the H90? No. The H90 needs 12V DC center positive at up to 1 A on a 5.5 / 2.5 mm barrel jack. Use the included universal supply or a board output rated for 12V at 1 A or more.
Is the H90 true bypass? Eventide does not publish a true-bypass claim for the H90. Preset bypass and insert bypass are mapped to the PERFORM footswitches instead, with momentary states available.
Do delay and reverb tails survive a Program change? Yes. Eventide describes true spillover between Programs, so tails carry across when you change sound.
Can I use it for the four-cable method? Yes. With four inputs and four outputs and two independently placed inserts, the H90 is designed for four-cable-method rigs and for two independent stereo signals in Dual Mode.
How do I edit it from a computer or iPad? H90 Control connects over Bluetooth or USB-C from a computer or iPad and handles deep editing plus importing and exporting User Lists.
