A stompbox-size audio toolkit for on-stage, in the studio, and everywhere in between. Includes a quiet high gain mic-pre, 48V phantom power, and enough I/O and control for applications such as FX Loop for microphone signal processing (vocals, horns, strings, etc), signal splitting, and combining, complete re-amp setup, impedance, and gain matching, mixing and more.
Latching or momentaryfootswitch control of FX loop for performance effects
Works with a wide rangeof microphones including condenser and ribbon mics with up to 65dB of clean gain
Aux I/Oconnection supporting stereo input and send
Guitarampoutputandheadphonemonitoroutputwith separate master volume control
Operates on9V battery(no phantom power when operating on a battery)
48Vphantompowerfor condenser mics
BalancedXLRoutput which supports DI and line levels
Versatilemixcontrolsupports 3 modes
100% Dry w/FX blended in
Mic/FX balance control
100% FX (no Dry)
Use the MixingLink as a compact studio mic pre for recording with Pro Tools, Ableton, or any other D.A.W.
Use the MixingLink to connect a microphone to your favorite stompbox(es) to add effects to your vocals.
Use the MixingLink as a hotel practice amp.
Use the MixingLink as an A/B Box to switch between two instruments.
Use MixingLink to split and blend one instrument between two amplifiers.
Use MixingLink as a mixer to connect multiple sources to an amp or headphones.
Video review: MixingLink Mic Preamp with FX Loop
Jacks position on top
Digital or Analog
Current Draw, mA
Input Impedance, kΩ
Output Impedance, Ω
Electric Guitars Vocals Bass Guitars Acoustic Guitars Other Instruments
